GPIO Expansion Board is an advanced product designed for Raspberry Pi Pico to enhance the learning experience for the user. It would help users to develop the projects based on their ideas with the utilization of Raspberry Pi Pico. The work of the Raspberry Pi Pico GPIO Expansion Board is to break out all the pins and power of the Raspberry Pi Pico development board via two ways(male or female header). It allows the user to connect it to other components with the help of a jumper wire.
Main Features:
2 X Programmable Independent Controlled Led (Green), 1 X Power Led, 1 X Independent Controlled Push Buttons.
Easy to interface: Male and Female Berg Connection Interface ( Jumper cable connectors ).
Can Connect with all the variants of Sensors / Modules.
Board Details:
Power Indicator : 1 X RED LED ( Indicate PICO is Powered ON/OFF ).
Push buttons : Release (Not Pressed) = Logic 0 , Pressed = Logic 1 (INPUT).
Programmable / Test Led : 2 X Green LED, OUTPUT : LED On = 1, LED Off = 0 .
*Note: By default, Cathode Pins of Programmable LEDs is connected to Ground.
